Skeleton bucket suitable for Verachtert CW30 / CW40 / 1200 mm / cat. 4G

Description

Skeleton bucket suitable for Verachtert CW30 / CW40 / 1200 mm / cat. 4G:

Offered EH skeleton bucket suitable for CW30 / CW40 to suit excavators from 24 to 30 Tonnen is 1200 mm wide and has a capacity of 944 l.

Basic parameters:
1. Sidewall made of steel S355J2, material thickness: 12 mm
2. Side cutting edge made of steel S355J2, material thickness: 25 mm
3. Cutting edge made of HARDOX HB500, dimensions: 40×300 mm
4. Side cutting edge knife made of HARDOX HB400, material thickness: 12 mm
5. Ribs made of steel S355J2, material thickness: 20 mm
6. Adapter: suitable for CW30 / CW 40
7. Welded teeth CAT J350

*Other adapters possible, suitable for e.g. Lehnhoff MS, Verachtert CW, OilQuick OQ, Martin, Miller, Schaeff, JCB, Cat, Zeppelin ZM, Volvo S, Liebherr SW, Atlas SMP, Terex, Hitachi ZX.

We provide a 12 month warranty on the welds.
All products are delivered with a nameplate and the CE marking.

More information about our products can be found here.

You can also find videos about our excavator attachments on our YouTube channel.

Product images are for illustrative purposes only and may differ from the actual product.
